Customized: Aluminum Casting Equipment for Drone Interference

This device is customizable and can be tailored to different frequency bands according to the usage location and needs. It can be made with 4-12 channels. It can meet the different needs of customers.

编号：

联系我们

Product Description
Table
Map

Device Type

It is a counter-drone fixed device,which is mainly used to interfere with or capture illegal drones in flight to protect specific areas from their influence.

Materials and Design

Cast Aluminum Frame: The device's body is made of cast aluminum, which provides good wear resistance and scratch resistance, as well as waterproofing, helping it operate normally in various environments.
Heat Dissipation Design: A well-designed structure facilitates heat dissipation, ensuring that the device can operate for extended periods without overheating, thereby improving reliability.

Antenna Technology

- The new antenna uses a omnidirectional antenna with high gain, which is better at receiving signals and reducing interference compared to the previous flat antenna.

- The antenna is directly connected to the host, making the system more streamlined and reducing potential failure points.

Range of Interference and Adjustable Functions

- The interference range can reach up to 500-3000 meters

- The frequency and power can be adjusted according to the shielding needs, which allows operators to flexibly configure the equipment according to specific circumstances to achieve the best results. For example, in some cases, a strong interference may be required, while in other cases, only a minor interference may be needed to avoid accidentally harming legitimate aircraft.

Product specifications

Model	BF-W400L
Flight range drone shield	500-3000 m (different number of antennas and chassis configurations).
Output Power	220W
Power dissipation	380W
Chassis size	50·38·24cm
Antenna Size	70·5cm
Host weight	About 28 kg
Working temperature	-40 ℃ ~ 75 ℃
Working time	Use of uninterrupted plug
Relative humidity	35～85%
Installation	Hang on the wall or install with a stand
Suitable mounting height	3～15m
Body Material	Aluminum Alloy
Accessories	Appropriate antenna, other spare parts
